Uniview NVR501-16E-IX-G 16-Channel Network Video Recorder with 1 SATA Bay
The Uniview NVR501-16E-IX-G is a 16-channel network video recorder for IP video surveillance. It is built to receive, store and play back video from network cameras, forming the recording core of a digital CCTV system. Instead of recording analogue signals through coaxial cable, the recorder works with cameras that send their video over an Ethernet network, which makes system design more flexible and easier to expand.
Key features
- 16 channels for connecting up to sixteen IP cameras
- One SATA bay for an internal hard disk drive used for video storage
- Network-based recording and playback for IP camera streams
- Compact design suitable for small and medium installations
- Supplier model reference UN-NVR501-16E-IX-G
- Supplier description notes SEEKFREE support; check documentation for details
Recording and storage
Video recorded by the NVR is saved to the hard disk installed in the single SATA bay. The amount of footage that can be stored depends on the disk capacity, the video resolution, the frame rate and the recording mode selected. Before installation, plan the storage size according to how many days of footage you need to keep. Using a hard disk designed for continuous surveillance use is generally recommended, but confirm the supported disk types and capacities in the product documentation.
Network connection
As a network video recorder, the unit relies on a working IP network. Cameras should be on the same network segment, or reachable through the correct routing, so the recorder can receive their streams. Plan IP addresses, switch ports and cable runs in advance. Adequate network bandwidth is important when many cameras stream high-resolution video at the same time.
Installation and setup
- Install the hard disk in the SATA bay and secure it correctly
- Connect the recorder to the network and to the monitor or display
- Add the IP cameras and check that each channel shows a live image
- Configure recording schedules, motion or event settings where required
- Set user accounts and passwords to limit access to the system
Typical uses
This recorder suits projects that need central recording of several IP cameras in one location. Typical applications include shops and retail premises, offices and reception areas, warehouses and stock rooms, car parks, schools, small industrial sites and residential buildings with multiple entry points. It can also be used by installers who need a straightforward recorder for a 16-camera system.
Points to check before ordering
The supplier information for this item is brief. Before purchasing, confirm the compatible camera models, maximum resolution per channel, supported hard disk capacity, video output options, power requirements and the exact meaning of the SEEKFREE reference. Also confirm the warranty and support terms with the supplier, as these are not part of the product description.
Summary
The Uniview NVR501-16E-IX-G offers 16 channels and one SATA bay for storage in a compact network video recorder. It is a practical choice for IP surveillance projects that need reliable central recording, flexible network connection and simple expansion with compatible cameras.
